CLG777A－777A Perkins III

Gross Power	74.5 kW (100 hp) @ 2200 rpm	101.29 ps
Net Power	72 kW (97 hp) @ 2200 rpm	97.89 ps
Operating Weight	8400 kg	18519 lb
Maximum Digging Depth	4440 mm	14’7”
Maximum speed	5.9 - 36 km/h	4-22 mph
Turning Radius Outside of Front Tire w/o single braking	4400 mm	14’5”
Turning Radius Outside of Bucket w/o single braking	5554 mm	18’3”
Turning Radius Outside of Front Tire w/ single braking	3450 mm	11’4”
Bucket Breakout Force, General bucket	59.3 kN	13331 lbf
Bucket Digging Force	58.2 kN	13084 lbf
Maximum Dump Height (Loading)	2691 mm	8’10”
Loading Height (Digging)	3586 mm	11’9”
Model	Perkins 1104D-44TA	Perkins 1104D-44TA
Emission Standard	EPA Tier 3 / EU Stage IIIA	EPA Tier 3 / EU Stage IIIA
Standard Bucket Heaped Capacity	1 m³	1.3 yd³
Standard Backhoe Bucket Heaped Capacity	0.2 m³	0.3 yd³

CLG777A－777A Weichai II

Gross Power	70 kW (94 hp) @ 2200 rpm	95.17 ps
Net Power	68 kW (91 hp) @ 2200 rpm	92.45 ps
Operating Weight	8400 kg	18519 lb
Maximum Digging Depth	4440 mm	14’7”
Maximum speed	5.9 - 36 km/h	4-22 mph
Turning Radius Outside of Front Tire w/o single braking	4400 mm	14’5”
Turning Radius Outside of Bucket w/o single braking	5554 mm	18’3”
Turning Radius Outside of Front Tire w/ single braking	3450 mm	11’4”
Bucket Breakout Force, General bucket	59.3 kN	13331.17 lbf
Bucket Digging Force	58.2 kN	13084 lbf
Maximum Dump Height (Loading)	2691 mm	8’10”
Loading Height (Digging)	3586 mm	11’9”
Model	Weichai WP4G95E221	Weichai WP4G95E221
Emission Standard	EPA Tier 2 / EU Stage II	EPA Tier 2 / EU Stage II
Standard Bucket Heaped Capacity	1 m³	1.3 yd³
Standard Backhoe Bucket Heaped Capacity	0.2 m³	0.3 yd³
