- Delivering 5-10% more power at the same RPM, this machine ensures instant power on demand, making every operation smooth and effortless.
- Featuring dual pump convergence with priority given to steering, it achieves a swift 20-second one-button lift, enhancing lifting efficiency by over 30%.
- Adopting a two-layer/triple-layer channel beam trapezoidal structure, it excels in bending and torsion resistance, perfectly adapting to the harsh conditions of mining sites.
- Equipped with front oil-gas suspension as standard, it ensures a comfortable and stable ride, thereby prolonging the vehicle’s lifespan.
- With independent relay valves controlling the brakes of the front, middle, and rear axles respectively, the braking system responds swiftly and can rapidly disengage, ensuring prompt reactions.
- Backed by LiuGong’s extensive experience and technical accumulation in Stage IV products in the construction equipment sector over the years, the quality of its after-treatment systems is highly reliable.
DW105A
Payload:
70,000 kg
Rated power:
382 kW
Struck Capacity:
36 m³
Product Features
DW105A
DW105A
Specifications
| Net Machine Weight | 36,000 kg |
| Payload | 70,000 kg |
| Max. Gross Machine Weight | 106,000 kg |
| Struck Capacity | 36 m3 |
| Heaped capacity (SAE 2:1) | 43 m3 |
| Engine Model | YC6K520 |
| Emission regulation | Tier 3 / Stage III |
| Rated Power | 382 kW (512 hp) @ 1,900 rpm |
| Transmission Model | FAST 8DS240A |
| Maximum travel speed | 37 km/h |
| Dimension | 6,876×3,440×1,750 mm |
| Tire | 16.00R25 |
| Download Brochure |
| Net Machine Weight | 36,000 kg |
| Payload | 70,000 kg |
| Max. Gross Machine Weight | 106,000 kg |
| Struck Capacity | 36 m3 |
| Heaped capacity (SAE 2:1) | 43 m3 |
| Engine Model | YC6K520 |
| Emission regulation | Tier 3 / Stage III |
| Rated Power | 382 kW (512 hp) @ 1,900 rpm |
| Transmission Model | Allison 4800 |
| Maximum travel speed | 37 km/h |
| Dimension | 6,876×3,440×1,750 mm |
| Tire | 16.00R25 |
| Download Brochure 1 Download Brochure 2 |
※For reference only.
